Colour
Allergy UK Awarded
Filtration System
Hitachi’s Air Purifiers were awarded the Allergy UK Seal of Approval in recognition of their proven ability to reduce exposure to allergens.
Stainless Clean System
The stainless filter is not only hygienic but also easy to clean.
Stainless Steel Coating Flap
Eliminate Bacteria*1
Stainless Net (Outlet)
Eliminate Bacteria*1
Stainless Steel Coated Pre-Filter*2Eliminate Bacteria*1 Easy Maintenance
Washable Deodorizing Filter
Allergen-Free HEPA Filter
Silver Ion Fan
Suppress Bacteria*3
Testing authority: (1) and (2) Boken Quality Evaluation Institute, (3) Kitasato Research Center for Environmental Science Test method: JIS Z 2801 (film contact method) Test item: Attached bacteria Sterilization method: Using the metal ion contained in stainless steel Test results: 99% of bacteria eliminated after 24 hours.
*2Stainless-steel coating.
Testing authority: Boken Quality Evaluation Institute Test method: JIS Z 2801 (film contact method) Test item: Attached bacteria Anti-bacterial method: Anti-bacterial components included into the silver ion fan Test results: Anti-bacterial activity value 5.1 (anti-bacterial effect is present when the activity value is more than 2.0).
Deodorizing Filter
Filter can be washed with water to restore deodorizing power*. This helps to reduce four major types of odor bases: nitrogen, aldehyde, acid and Sulfur components.
Results of odor elimination tests in a 25㎥ test space using single odor components. Odor elimination performance differs under conditions of actual use in a room. Tests performed by Hitachi.
Results of deodorizing performance tests performed in a 1㎥ test space with single odor components. Deodorizing performance differs depending on the space where the unit is actually used. Testing authority: Japan Food Research Laboratories.
*Depending on the odor, washing with water may not eliminate it. Restoration of deodorizing performance by washing with water gradually declines.
Allergen-Free HEPA Filter
Multi-layered structure of Allergen-Free HEPA Filter for fine dust effectively catches fine particles including dust, cedar pollen and airborne mold. It also suppresses the PM2.5.
HEPA Filter Collects99.97%
or more dust containing fine particles of 0.3µm at a rated air flow
Based on performance of a single HEPA filter complying with the JIS Z 8122. Overall room dust removal performance may differ.
The allergen-free components of the HEPA Filter for fine dust suppress the activity of cedar, birch & ragweed pollen, dust mite dung & cat dandruff that have been captured.
This is the effect on airborne viruses and bacteria after 13 minutes in a 25㎥ test space, not the proven effect in a space where the filter is actually used. Effects may differ according to conditions and method of use. Tests performed conform to the Japan Electrical Manufacturers’ Association standard (HD-124).
Testing authority: Kitasato Research Center for Environmental Science Test method: Performance evaluation test conforming to the Japan Electrical Manufacturers’ Association standard (HD-124) conducted in a 25㎥ test space. Same test applied for bacterial suppression effect Test item: 1 type of airborne virus/1 type of airborne bacterium Test results: 99% or more suppressed in 13min Model used: EP-L110E (with max air flow).
Wide and Speedy
Dust Collection
Increased air intake surface area achieved on the back lateral sides. By widely collecting dust from both sides, a 13㎡ room can be quickly purified.
PM2.5 Sensor
Switches to high-sensitive detection mode and purifies fine dust with max air flow operation.*1 HEPA filters enable the collection of fine particles*2 of 0.1µm and larger (0.5µm or larger with the dust sensor detection). Continues super-sensitive patrol operation even after cleaning the air.
PM2.5 is a collective term for particulate matter of 2.5µm or less in diameter. Removal of particulate matter less than 0.1µm has not been verified. Further, not all harmful substances in the air can be removed. Results were obtained in a sealed 32㎥ space and not in an actual living space.
*1Comparison with normal automatic air purification mode. Time required for reducing an initial concentration of approx. 1,000µg/㎥ to 35µg/㎥. Normal automatic air purification mode: 38min, PM2.5 sensing automatic operation mode: 20min. Surveyed by Hitachi.
*2Cigarette smoke.
*3Odor sensor does not activate during the PM2.5 sensing mode.
Humidifying
Two selectable modes provide the desired level of humidity.
This humidifies clean air to increase the humidity in a room to about 50%. And it can be used in combination with the deodorizing course.
Room humidity can be increased up to about 60%*. This helps keep your skin moist in the dry season and when using air conditioning.
*Humidifying capability may change due to temperature, humidity and other conditions.
Low Noise Operation
During Silent airflow operation, the noise level is less than 15dB, so it won't disturb you when sleeping.
Touch Panel Operation
Touch panel has been incorporated on front glass panel.
Flat front glass panel is easy to clean – simply wipe off dirt. Reinforced glass is also scratch-resistant. Color does not fade and matches home interiors.
| Power Supply | AC220-240V 50-60Hz |
|---|---|
| Applicable Floor Space (m2)*1 | 68 |
| Humidifying Capacity (mL/h)*2 | Approx. 800 |
| Tank Capacity (L) | Approx. 2.5 |
| Mode & Course | Air Purify, Humidify, Skin Moist, Pollen, Odor, Rapid, Absence, Eco |
| PM 2.5 | with sensor |
| STAINLESS CLEAN | |
| Inverter | |
| Eco Mode (Efficiency vs Silent mode (%) | 14 |
| Removable Odors | Pet, Tobacco, Cooking, Rotten vegetables, Rotten fish, Grilled meat, Toilet, Sewage outlet |
| Suppressible Substances | Mold, Bacteria, Viruses, Cedar pollen, Dead house dust mite |
| Air Flor Rate | Max, High, Medium, Silent |
| Air Flow | Clean Air Mode (m3/min) : Max : 9.0, High : 4.0, Medium : 2.7, Silent : 1.1 |
| Clean Air & Humidifying (m3/min) : Max : 6.7, High : 4.0, Medium : 2.7, Silent : 1.6 | |
| Power Consumption | Clean Air Mode (W) : Max : 85, High : 16, Medium : 10, Silent : 7 |
| Clean Air & Humidifying (W) : Max : 43, High : 16, Medium : 10, Silent : 8 | |
| Sound | Clean Air Mode (dB) : Max : 54, High : 38, Medium : 30, Silent : 15 |
| Clean Air & Humidifying (dB) : Max : 48, High : 38, Medium : 30, Silent : 20 | |
| Filter Type (Approx. filter life) | Washable Prefilter*3 : (Stainless) |
| Allergen-free HEPA Filter*3 : H13 (10 years) | |
| Washable Deodorizing Filter*3 : (10 years) | |
| Humidifying Filter*4 : (120 months) | |
| Off Timer | 4 hours or 2 hours |
| Sensors | Odor, Dust, Humidity, Temperature |
| Power cord (m) | 1.8 |
| Dimensions (H x W x D ) (mm) | 669 x 360 x 254 |
| Weight (kg) | 12.5 |
| Body Color | Champagne |
